Product Details:
|
| Product Name: | FlapJack | Model No.: | C-300R |
|---|---|---|---|
| Beam Angle: | 75° | CRI: | ≥93 |
| Voltage: | DC7.4V-14.8V | Weight: | 742 G |
| Battery Type: | Rechargeble Lithium Battery, 2200mAh, 7.4V | Illuminance: | 2050Lux/0.5m, 570Lux/m |
| High Light: | film led lights,led lights videography |
||
Round Ultra Thin FlapJack Portable LED Video Light Flicker free Dimmable
Product Specifications
| Model Number | C-300R |
| Demension | φ260 × 46 mm |
| Power | 30 W |
|
Color termperature |
5600K (±300K) |
|
Illuminance |
2050Lux/0.5m, 570Lux/m |
| Battery type | Rechargeble Lithium battery, 2200mAh, 7.4V |
| Battery life time | Charge and Discharge for approx. 500 times |
| Materil | Aluminum Alloy |
| Features | LCD display screen, Ring Bracket |
| Continuous working time | Approx 2 hrs |
What's Includied
1 x LED C-300R Light
1 x 4400 mAh battery
1 x Battery charger
1 x 12V 2A AC charger adapter
1 x 12V 40W AC adapter with power cord
1 x Stand Stud
1 x Carry case
Product Characteristics and Advantage
Lishuai presents the newest idea in LED lighting; the Flapjack LED Edge light. Instead of forward-facing LEDs like in a conventional panel, the Flapjack's LEDs are mounted around the outer edge, aimed inward at layers of diffusion material.
C-300R Flapjack light is composed of 60 pcs of ultra bright LEDs which lifetime reaches 50000hrs. Lateral LED layout makes the light much softer, no need additional diffuser. It produces a soft, even light and can be fully dimmable from 10-100%. The light A back-lit LCD indicator shows light level and battery life status.
C-300R can runs on either AC power or a NP-F style rechargeable battery, both of which are included in the kit. Flapjack kits include a rechargeable Sony NP-F style lithium-ion battery, charging station, and an AC adapter - all in a fitted hard-shell case with a handle which makes convenient to carry to any where.
The built in 1/4-20" mounting points let you attach the Flapjack directly to a tabletop tripod, or lighting clamp. It produce little heat and have a very low current draw, several Flapjacks can easily be run on a conventional household circuit. Leave them running all day without fear of cooking your subject, or breaking the bank on your electrical bill.
Operation instructions
1. Install the battery onto the light.Turn on the power & brightness dimming kob and light works.
2. The right side of LCD shows the battery level .
Four columns: 75%-100%
Three columns: 50%-75%
Two columns: 25%-50%
One column: 10%-250%
No colimn: 10% or less
3. Pls adjust the brightness (10%-100%) of C-300R through the power & brightness dimming knob.
4. When the colum on the LCD flicks, it means the battery runs out, pls press the installation and uninstallation button to take off the battery. It takes 4-5hrs to recharge it.
Cautions:
1. It is no need to replace the LED bulbs in normal use.Please do not disassemble the light or solder the LED bulbs by the non-professionals.
2. Please do take off the batteries when in storage.
3. Please do discharge and recharge the battery at least once for every month if it is not in use.
4. It is not allowed to drop or impact the light to avoid fire.
5. It is not allowed to short circuit the battery,or it may seriously damage the battery or cause a
fire.
6. It is not allowed to throw the battery into fire.
7. The 12V 2A adapter is used for battery charging only. Pls do not use it on the light directly.
Warranty:
The LED light is guaranteed for 12 months.
The battery is guaranteed to be charged and discharged for 500 times.
