Dual Color LED Ring Light Video LED Photography Lights Kit Metal Material

Dual Color LED Ring Light Video LED Photography Lights Kit Metal Material


Product Characteristics


• C-318RLS is composed of 120pcs of ultra bright LEDs. Its color temperature can be adjustable from 3200K to 5600K. And the LEDs' lifetime reaches 50000 hrs.
• It's housing is made by metal, mainly aluminum alloy. So it is very solid and easy for heat dissipation.
• It's also compact and protable. This is a pro kit with carrying case, NP batteries and chargers, etc. It's very convenient to carry.
• It is PMW integrated digital designed,dimmable 10%-100%, flicker-free.
• LCD screen makes it more convenient to display the color temperature,brightness and battery level.
• Lateral LED layout makes the light much softer,no need additional diffuser.
• Suitable for indoor and outdoor photography and videigraphy, portrait, wedding, Interview and especially good for baby photography.





DIAGRAM

Name of the parts:

1. Front diffuser panel
2. Battery release button
3. DC Input
4. Power and brightness dimming knob
5. CT dimming knob
6. LCD Screen
7. Camera connecting bracker


Operation

1. Install the battery onto the light.Turn on the power & brightness dimming kob and light works.

2. The right side of LCD shows the battery level .
Four columns:   75%-100%
Three columns: 50%-75%
Two columns:    25%-50%
One column:     10%-250%
No colimn:         10% or less

3.  Pls adjust the brightness (10%-100%) and color temperature (3200K-5600K) of C-318RLS through the power & brightness dimming knob and CT dimming knob.

4. When the colum on the LCD flicks, it means the battery runs out, pls press the installation and uninstallation button to take off the battery. It takes 4-5hrs to recharge it.


Cautions:

1. It is no need to replace the LED bulbs in normal use. Please do not disassemble the light or solder the LED bulbs by the non-professionals.
2. Please do take off the batteries when in storage.
3. Please do discharge and recharge the battery at least once for every month if it is not in use.
4. It is not allowed to drop or impact the light to avoid fire.
5. It is not allowed to short circuit the battery,or it may seriously damage the battery or cause a fire.
6. The 12V 2A adapter is used for battery charging only. Please do not use on the light directly.


Warranty:
The LED light is guaranteed for 12 months.
The battery is  guaranteed to be charged and discharged for 500 times.
